The Best 2024 Tesla Model 3 Wheel Spacer Fitment Guide
Last day BONOSS wheel spacer engineers got to test out the 2024 Tesla Model 3 (Highland) Standard Range. Here are the OEM sizes of this car:
- Tire size: 235/40ZR19
- Rim size: 8.5Jx19
- Wheel offset: +38
- Flush wheel spacer size: front 10mm / rear 20mm
- Bolt pattern (PCD): 5×114.3mm
- Center bore (CB): 64.1mm
- Lug nut size: M14x1.5mm
If you are an owner of the 2024 Tesla Model 3 (Highland) Standard Range RWD and planning to buy a fresh set of forged wheel spacers from us, don’t hesitate, BONOSS company has got you covered.
The Fender Gap Measurement
Take a straight edge and place it against the outermost part of the rims/tires, then measure from the outside wheel to the fender line. For more details, check out how to measure wheel spacers for my vehicle.
Front flush wheel spacer sizes: 10mm
Rear flush wheel spacer sizes: 18mm or 20mm
The PCD CB Measurement
The bolt pattern of the 2024 Tesla Model 3 Standard Range RWD is 5×114.3mm and the center bore is 64.1mm. Wheel lug pattern is one of the key factors to identifying wheel spacer dimensions.
2024 Tesla Model 3 bolt pattern (PCD): 5×114.3mm or 5×4.5″
2024 Tesla Model 3 center bore (CB): 64.1mm
The Wheel Stud Length Measurement
Measuring the OEM wheel stud length (the protruding part of the wheel hub) is important to know whether you need to cut wheel studs for 2024 Tesla Model 3 wheel spacers.
Then measure the cavity depth in your wheels to check out how much it will allow for the stud to go past the wheel spacers.
If the wheel pockets depth + spacer thick ≥ stud length, then you don’t need to trim the stock wheel studs to fit wheel spacers.
For example, you don’t have to cut the OEM Tesla Model 3 wheel studs for 20mm wheel spacers.
2024 Tesla Model 3 Wheel Spacer Before and After
There are 15mm, 18mm, 20mm, 25mm, 30mm, 35mm, 40mm, 45mm, and 50mm wheel spacers available for 2024 Tesla Model 3 Highland RWD. Selecting the right size is a personal decision based on your preferences.
For rear wheels, you can go with 20mm spacers for a flush stance, or 25mm spacers for a more aggressive wheel style.
It is a good idea to pick up some new aluminum wheel lug nut to decorate the wheels while get the best performance.
